Quick information
- Tare weight: 9900kgs
- Loading capacity: 45cbm
Built with a streamlined design and robust sealing, the cement tank trailer offers safe, dust-free transport and long-lasting performance under tough working conditions.
Production Pictures


Specifications Sheet
|
Bulk Cement Tank Semi Trailer |
|
|
Tare weight |
9900kgs |
|
Size |
10600mm*2500mm*3800mm |
|
Volume |
45cbm |
|
Tank body |
Q235B/4.5mm steel sheet |
|
End plate |
Q235B/6mm .ball shape |
|
Axle |
3 axles Fuwa brand 13T( can be customized) |
|
Suspension |
Mechanical suspension ( can be customized) |
|
Leaf spring |
Leaf spring 10pcs*90*13mm |
|
Manhole cover |
500mm manhole cover .2 sets |
|
Tire |
12R22.5 Triangle star brand 12pcs |
|
Wheel rim |
9.0 factory brand 12pcs |
|
Discharge valve |
4" disc valve |
|
Discharge pipe |
4" seamless steel tube |
|
Outlet pipe |
4" rubber hose.6m |
|
Kingpin |
JOST brand 2" bolt-in king pin |
|
Landing gear |
JOST C200 |
|
Engine |
Diesel engine: weichai brand model: 4102. |
|
Air compressor |
37 KW, 0.2Mpa. 1000r/Min |
|
Compartment |
Single |
|
Braking system |
WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
|
ABS |
Optional |
|
Light |
LED 8 side lights and 2 rear lights 2 width lamp |
|
Air-charging system |
2" main hole.2" check valve .1.5" safe valve.0.4Mpa.gauge |
|
Quadratic blow |
1" diameter check valve |
|
Painting |
Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
|
Accessories |
One standard tool box one spare tire carrier one crank one shaft head wrench four side light two rear light |
Efficient loading and unloading

-
Preserves cargo integrity during transfer. The system's gentle handling mechanism minimizes impact and friction on sensitive materials. This controlled process prevents product degradation, ensuring that powdered and granular goods arrive at their destination in the same high-quality condition as when they were loaded.
-
Ensures clean, low-loss material movement. The sealed pneumatic design effectively prevents external contaminants like moisture or dust from entering the tank. This clean environment also drastically reduces residual waste stuck inside the vessel, safeguarding your valuable cargo from point A to point B.
-
Provides stable and dependable cycle performance. With a focus on consistent pressure and flow control, the system allows drivers to execute unloading cycles with predictable results. This reliability minimizes the risk of material blockages or system errors, turning each transport run into a secure and worry-free operation.
Protects the long-term resale value of the tractor and auxiliary equipment. A pneumatic tanker that regularly experiences pressure spikes or material blockages can place unexpected stress on the truck's PTO, compressor, and hydraulic systems. By maintaining consistent flow control and avoiding sudden pressure surges, this trailer reduces mechanical wear on the entire combination unit. When it comes time to sell the tractor or upgrade the fleet, vehicles that have worked behind this system command higher prices in the used market because they haven't been abused by erratic unloading cycles.
Product Application
When shipping dry bulk commodities across long distances, product loss and moisture damage are two of the biggest concerns for logistics operators. The cement tank trailer addresses these issues directly. Its fully enclosed construction keeps outside humidity away from sensitive materials like cement or lime powder, while also preventing spillage along the route. From mountain roads to unpaved job sites, the cargo stays clean and intact. Industries ranging from road construction to mining operations have adopted this equipment for its ability to deliver dry goods in perfect condition, trip after trip.
